N20 DC Gear Motor - High Power

N20 DC Gear Motor - High Power

(0 review)


The Turnabot N20 Motor is the most popular size in the N-Series, offering an outstanding balance of power, speed, durability, and weight. After extensive testing across more than a dozen suppliers, this motor was refined specifically for small combat and competitive robots.

At just 9.6 g, the N20 delivers torque levels many builders expect only from much larger motors. Higher-speed variants often exceed available traction, spinning tires even in 1-lb robots.


Specs:

Weight: 9.6 g

Dimensions: 37 mm x 12 mm x 10 mm

Stall Current on 2S: 2.0+ amps


$ 12.30 $ 12.30
( $ 0.00/Units)
  • RPM
Contact Us
 See Terms and Conditions
Available Speeds at 2S (laser-etched on case)Electronic Speed Controller (ESC) Compatibility & Power NotesNotes on Use

Available Speeds at 2S (laser-etched on case)

  • 101 RPM

  • 800 RPM

  • 1400 RPM

  • 1400 RPM with high-temperature windings and hardened shaft

  • 2000 RPM

  • 3000 RPM


Electronic Speed Controller (ESC) Compatibility & Power Notes

  • One N20 per drive side using a Standard Malenki on 2S

  • Up to two N20s per drive side using a Malenki HV on 2S

  • One N20 per drive side using a Malenki HV on 3S


Notes on Use

These motors are extremely powerful for their size. Avoid prolonged stalling, as continuously applying power while the motor is prevented from spinning can damage any brushed motor of this performance level.


(Price is for one motor.)
